Is used to control the type of attachments that can be added to outgoing emails from NX. (Comma delimited list - e.g. .pdf, .png. xml) Acceptable email attachment types include:

• .doc
• .docx
• .xml
• application/msword
• application/vnd
• openxmlformats-officedocument
• wordprocessingml

Labels for the six Agent Analysis fields. Once set, these field labels are available in Code Setup > Debtors Debtor (Agent) Analysis Codes for the definition of data in the agent analysis tables. This data is then able to be set against agents in Debtors/Details/Analysis tab.

This setting allows an Agent branch code (or codes) to be set up against individual users and restricts the user to making bookings only for an agent whose branch code is in this setting. (Comma delimited list - e.g. NZ,US,AU).

The Agent Analysis field number (1 - 6) that the AGENT_BRANCH setting (above) is validated on.

The message code that is to be put on the air service line during the PNR download which determines which message line format will be used.

The service type that is to be used when creating a service line via the PNR download function.

When Y(es), the default radio button setting for Booking recalculation is "All Except Override".

Allows negative release days in the Supplier allocation application.

Labels for the six Booking Analysis fields. Once set, these field labels are available in Code Setup > Bookings Booking Analysis 1-6 for the definition of data in the booking analysis tables. This data is then able to be set against bookings in Header Details tab.

Determines the basis of how the Agent balance is calculated when being compared with the agent credit limit. The default is total outstanding including future entered and aged.

• CurrentAndFuture

• Current

• Warning

These three settings are used to provide the start numbering sequence for Debtors accounting documents — Credit Notes, Invoices and Receipts.

Defining the value for this setting activates the Batch Agent Invoicing function. This allows for batch numbers to be allocated to invoices created in 'Batch Agent Invoicing' and then be recalled via that number during the receipting process.

Defining a value (alpha or numeric) for this setting allows for a 'Batch Prefix' to be added to the batch number defined in AR_NEXT_BATCH.

File path to search for attached documents. Hosted client locations will need to be relative to the home directory of the messaging webservices.

Switches on the Auto messaging system. Additional options are also required to complete functional setup. The available options are: G = Group only; F = FIT only, B = Both Group & FIT; N = None.

For hosted NX systems, the print function needs an Azure Fileshare Account. The account name needs to be in this INI setting.

Azure Fileshare storage key for the account defined in AZURE_FILESHARE_ACCOUNT.

The 3 character currency code of the currency that the final accounting will be done in. i.e., the currency of the country the system is domiciled in. This must match the currency code for the base currency that is set up under Currencies.

NOTE: Auditing of a booking is available if there is an associated archive database (speak with your local Tourplan Office if you are interested in this feature)

To enable booking auditing for all users select 'Y', the setting will automatically default to 'N'.

The default name for a Group booking generated via the Operations > Book On function for rolling up FIT Package Bookings into a Group series departure. Valid values are PCM – PCM Name or Service – Package Service Description. When setting this value it should be remembered that the BOOKON_PREFIX and the BOOKON_SUFFIX value are prepended and appended to the Booking Name (as obtained from the BOOKON_NAME variable), and there is a maximum limit of 60 characters for a booking name.

A prefix which will be prepended to the BOOKON_NAME when the Group booking (generated via Operations > Book On) is created.

There are two methods of outputting Group rooming lists — as text Notes (with a special note category), or as a passenger name record stored in the names table. When a Group booking is generated via the Operations > Book On function for rolling up FIT Package Bookings into a Group series departure, the system needs to know which method of rooming list is being used. The valid values are Notes or Booking.

If NOTES is being used for the BOOKON_ROOMLIST, then the note category created specifically for rooming lists must be entered as the value here.

A suffix which will be appended to the BOOKON_NAME when the Group booking (generated via Operations > Book On) is created.

The BSP Plate record which will be used as the default BSP Plate.

Determines if BSP Processing is in use. Options - (Y/N), this setting will automatically default to 'N'.

The default BSP supplier that will be used if the BSP Supplier Plate is not defined.

This setting controls the note category to be displayed on the more info cancellation policy tab within the service search screen.

The user company software license name. This is used on report headings, login screens etc.

Allow a booking that has a component tour in it to be copied. There are 3 valid values:Yes, No, Warning.

When set to 'Y', allows a Country description to be set up and Countries defined. These are then able to be used in the Service lookup process in PCMs and Bookings.

NOTE: The term Country is a default description. The INI setting CTR_LABEL allows a descriptive label to be set. The important thing is that the Country (and Destination when set to Yes, allows a Destination description to be set up and Destinations defined. These are then able to be used in the Service lookup process in PCMs and Bookings and can be used as two additional descriptions in conjunction with the Location, Service, Supplier coding that services use.

The label to describe the Country level enabled in CTR_ENABLED above.

The current version of the Tourplan SQL Database.

Labels for the six Database Analysis fields. Once set, these fields labels are available in Code Setup > Product for the definition of data in the Database analysis tables. This data is then able to be set in the Options Cost Detail screen of services in the Product application.

As DATETIME_FORMAT_DISPLAY, but for those fields that only display dates (not dates and times). See Date/Time About INI Setting Field Headings.

The format of date entry into date fields. See Date/Time About INI Setting Field Headings.

NOTE: Having separate settings for Date Format Entry and Date Format Display means that dates can be entered in one format, but display in another—e.g., a date entered as 01/01/17 can display as 01 Jan 2017.

The default font that will be used in Notes and Messaging set up and editing screens. This setting applies system wide.

The following fonts will translate into the correct HTML styles.

The default font size that will be used in Notes and Messaging set up and editing screens. This setting applies system wide.

The default %age value that will be applied to expired Product rates when entered into PCMs and/or Bookings.

Default analysis codes for the six PCM Analysis fields. Once set, these values will default into the analysis fields in a PCM header when the PCM is created.

If multi-language enabled, this sets the default language used within Notes. The value used should be one of the values defined in the languages table.

When searching for bookings, there are four date fields — Travel Date From/To and Booking Date Entered From/To. This INI setting is used to define the default 'From' value for the Booking Date Entered range in the booking find/scroll. Can be either a specific date or number of months. If months is used, the value must be preceded by a minus (-) sign - e.g. -12

As DEF_BKG_FIND_FROM_DATE, but the default 'From' value for the Booking Travel Date.

When searching for PCMs, there are four date fields — Travel Date From/To and Booking Date Entered From/To. This INI setting is used to define the default 'From' value for the PCM Date Entered range in the booking find/scroll. Can be either a specific date or number of months. If months is used, the value must be preceded by a minus (-) sign—e.g., -12.

As DEF_PCM_FIND_FROM_DATE, but the default 'From' value for the Booking Travel Date.

An alpha or numeric value which will be used as a prefix on Deposit invoices.

NOTE: The transaction reference field (Invoice Number) has a limit of 20 characters. The prefix set up in this field must be counted as part of the maximum 20 characters.

When set to Yes, allows a Destination description to be set up and Destinations defined. These are then able to be used in the Service lookup process in PCMs and Bookings.

NOTE: The term Destination is a default description. The INI setting DST_LABEL allows a descriptive label to be set. The important thing is that Destination (and Country) can be used as two additional descriptions in conjunction with the Location, Service, Supplier coding that services use.

The label to describe the Destination level enabled in DST_ENABLED above.

Without being set (and if the setting is 'N'), the exchange rate used is the rate on the first date of the service. When 'Y', the exchange rate used is the rate on the Service Out Date.

External Air Service Allocated OK Status.

External Air Service Request Status.

External Air Service Cancelled Status.

The service status to apply when an external service has been disconnected from the external system.

The service status to be automatically applied to an External Service that has been allocated ok.

The service status to be automatically applied to an External Service that has been quoted.

The service status to be automatically applied to an External Service that is on request.

The service status to be automatically applied to an External Service that has been cancelled.

The maximum number of bookings that will be returned in a find bookings request. Numeric value and if 0 or not defined then there is no maximum.

The Currency Sub-code to use when Foreign Currency revaluations are being calculated.

Labels for the six General Ledger Analysis fields. Once set, these field labels are available in Code Setup > Financials for the definition of data in the Financial analysis tables.

This setting controls which Package Departures are displayed during the Operations > Book On procedure. When set to 'Y', those packages which have 0 bookings on them will not be displayed. This setting effectively sets/unsets the checkbox which is available in the Operations exe to control this function.

When commissions are paid to agents, the standard setting 'N' will generate an invoice showing Retail, Less Commission = Net. e.g., 1000.00 - 100 = 900.00. Internally (not displayed on an invoice transaction) a record is stored of the commission amount of each service. When this setting is 'Y', there are no commission records created and the invoice amount is calculated as 900.00 - 0.00 = 900.00.

This is a comma delimited list of Languages available in the UI [(CN)Chinese, (DE)German, (EN)English, (ES)Spanish, (FR)French, (IT)Italian (JP)Japanese].

Manual fight service dropoff remarks format.

Manual fight service pickup remarks format.

NOTE: The above two INI Settings (MANUAL_FLIGHT_DROPOFF and MANUAL_FLIGHT_PICKUP) control the format of manual flight sector pick up and drop off detail) Setting these two settings can control the appearance and order of the data within the populated field. For Example setting them to:

• FLIGHT, LOC will produce BA1234 (Flight), London (Location) - This is the default setting
• LOC will produce just the location
• LOC, FLIGHT will produce London (Location), BA1234 (Flight)

If tax is applied to booking mark-up e.g. GST or VAT, then the tax must be specified in this setting. The value entered must match a valid tax code as set up in Tax.

Defines the maximum size of message attachments in Bytes.

This INI Setting defines the maximum bytes size of notes entered. The value defaults to 1,000,000 bytes. The maximum value permitted is 5,000,000 bytes.

The maximum number of concurrent users the Tourplan system is licensed for.

More Information geo notes to show as maps [e.g. INF,12,SGN,14].

More Information notes to show [e.g. INF,CON,DES].

More Information Value Adds [e.g. OptionRateText(1,2);RateValueText(1,2)].

The top-level directory for print files printed via Azure Hosted systems.

Dependant on how the (either Azure hosted or In House) system printing is set up, sub-directories can be set up on a user basis. This setting can be per user and if sub-directories per user are being used, the top level per user is MSG_FILE_TOP_LEVEL_DIR/MSG_FILE_USER_SUB_DIR.

During output of supplier messages, a radio button is available which offers several options for consolidation—i.e., if the same supplier is used more than once in a booking, send the details of all that supplier's requirements in one message rather than individual messages. Setting this value to Yes will default consolidation by supplier.

The email system used (Outlook or Raw)

When MULTI_COMPANY_SUPPORT is set to 'Y', the accounting period that Multi Company accounting is to commence is entered in to this setting. This must be an accounting period in the future - Multi Company accounting cannot be retrospectively applied. The Start Period format is yyyymm - e.g. 201912.

Is Multi Company Accounting to be used. (Y/N).

Nationality Analysis Code.

This setting is used to set the starting reference number for bookings. Once set, it should not be changed without contacting Tourplan Support.

When set to 'Y', agent commission will not be applied to invoice lines which are manually inserted.

Sets the default radio button in the bookings insert scroll which determines whether All Price Code services, System Price Code services, Applicable Price Code services are displayed or if manual price code filters are to be used.

This INI setting has four possible values:

1. All. Tourplan will display MULTIPLE lines per product, i.e. one line per price code. In effect, the system will show all products whether or not:

   1. The header price code is blank

   2. The INI-Setting USER_PRICECODE_OVERRIDE is used

   3. The price codes are valid agent price codes.

2. System. Tourplan will display ONE line per product based on whether or not the header price code is blank:
   1. If the header price code is “blank”, Tourplan will display products in the following order:
      1. With the price code from USER_PRICECODE_OVERRIDE INI-setting (if set)
      2. With the first valid agent price code
      3. With blank price code (whether or not “blank” is a valid agent price code)
   2. If the header price code is NOT “blank”:
      1. Tourplan will display ONLY products that have the same price code as the header price code (whether or not the header price code is a valid agent price code).
3. Selected. This setting works the same as OPTIONSCROLLPCRADIODEF = A. It is only used if all price codes are to be shown, but the ability to filter a specific price code needs to be retained.
4. Applicable. Tourplan will display MULTIPLE lines per product, i.e. one line for each applicable price code. Applicable price codes are the header price code + the price code used in INI-setting USER_PRICECODE_OVERRIDE + all valid agent price codes.

Labels for the six PCM Analysis fields. Once set, these fields’ labels are available in Code Setup > PCM PCM Analysis 1-6, for the definition of data in the PCM analysis tables. This data is then able to be set against PCMs in the PCM Header screen.

The default initial service entry status code of a service line in PCMs.

When set to (Y)es, General Ledger audit data is saved to a log table.

Sets the default for the checkbox 'Retain Sell Price' when substituting a service in bookings.

Either allows or denies the user to change the setting in the 'Retain Sell Price'.

If set to 'Y', the system will record the product changes (Y/N).

(This INI setting works in conjunction with a Security Setting called View Change History)

The time in seconds that the system will poll the user’s message queue.

This INI setting controls the data displaying on the users landing page. The default setting for this is to filter bookings by Consultant. Available settings include: [Consultant, All, Branch, Department, or one of the 6 Booking Analysis codes].

This INI setting controls the data displaying on the users landing page. Users can define the number of days to search for recent bookings. The default setting for this is 7 days however users can select an alternative length from 0 - 28 days.

This is a comma delimited list of statuses which can be defined to omit any bookings from showing on the landing page.

This INI setting controls the data displaying on the users landing page. The default setting for this is to filter PCMs by Consultant. Available settings include: [Consultant, All]

This INI setting controls the data displaying on the users landing page. Users can define the number of days to search for recent PCMs. The default setting for this is 7 days however users can select an alternative length from 0 - 28 days.

This is a comma delimited list of statuses which can be defined to omit any PCMs from showing on the landing page.

The value in this setting must be the same as the corresponding setting in the Windows Regional settings on the computer that Tourplan has been installed on. The value for this setting is usually a period (“.”).

The system registration code.

The default colour for the cell displaying the allocation release period when any of the dates selected fall inside the release period. In hexadecimal format. See Colours About INI Setting Field Headings.

This setting determines how the name for the assignement will be generated. The available settings are:

• BR - Booking reference of the first service added to the assignment
• GEN - Generated name based on the group number and pick up date of the first service of the assignment
• LOC - Location description of the first service added to the assignement
• NONE - No default name generated, this setting is the same as if the INI is not inserted
• PROD - The 6 character product code of the first service added to the assignment
• SRV - Description of the first service added to the assignment
• SUP - Code of the supplier of the first service added to the assignment

Comma separated format for default resource assignment name [(None), (BR) Booking Ref, (PROD) Product Code, (GEN) Group Id, (SRV) Service Name, (LOC) Location Name, (SUP) Supplier Code].

This setting sets the default status to be used when creating new assignments.

Enable Service Based Tax Reporting [(Y)es, (N)o]. This is used in conjunction with the Debtors INI settings AR_TAX_ANALYSIS and AR_TAX_ANALYSIS_VALUE to have a Database Analysis Code set as a Tax Analysis field.

The default status code of a service line in bookings to indicate Free sold.

The default initial service entry status code of a service line in bookings.

The default status code of a service line in bookings to indicate all rooms have been taken from Allocation.

The default status code of a service line in bookings to indicate some rooms have been taken from Allocation.

The default status code of a service line in bookings to indicate the service is on Request.

The default status code of a service line in bookings to indicate the service incurs a Cancellation Penalty.

The default status code of a service line in bookings to indicate the service is Cancelled.

Setting this value to 'Y' will display a warning message when a booking currency is changed.

This value must be set to Yes before any service line colours associated with the service status will display. Valid settings are Yes/No/Off.

Sets the default for the checkbox 'Retain Pick-up/Drop-off Details' when substituting a service in bookings. (Y/N).

Validate the service option 'Sale From Date' and 'Sale To Date' fields when Substituting services. (Y/N).

Labels for the six Supplier Analysis fields. Once set, these fields’ labels are available in CodeSetup > Accounts Payable for the definition of data in the supplier analysis tables. This data is then able to be set against suppliers in the Creditors > Details > Analysis tab.

This setting is designed to recall information from an integrated system.

The base URL of the supplier confirmation application allowing suppliers to confirm services and accept payment via VCC (if required).

This setting controls which elements of the Markup/Discount/Commission matrix are to be obeyed when the data in a Tariff Writer spread sheet is being inserted or refreshed. Valid options are:

• No

• Yes With Blank Defaults

• Yes With Internet Defaults

System-wide setting to indicate whether values in bookings display Inclusive or Exclusive of tax.

When the rate of an accountable tax (GST/VAT etc) changes, the date of the rate change must be entered in this setting.

When an accountable tax rate changes, a new date range is inserted into the product database - the first season with the new tax rate, the last season with the old tax rate. This setting tells the system which cross-season tax rate to apply - [FIRST] or [LAST].

System-wide setting to set the time display formats. The seperator does not have to be a colon for example HH'mm would also work. Spacing between the values are counted as part of the required format so HH mm would mean a space between the hour is required.

Available values are as follows:

• HH:mm (Hours:Minutes) - Default
• HH - 24 Hours 2 digits 00-23
• H - 24 Hour 1 or 2 digits 0-23
• hh - 12 Hour 2 digits 00-12
• h - 12 Hour 1 or 2 digits 0-12
• mm - minutes 00-59
• a - am/pm indicator

System-wide setting to control the time entry. The seperator does not have to be a colon for example HH'mm would also work. Spacing between the values are counted as part of the required format so HH mm would mean a space between the hour is required.

Available values are as follows:

• HH:mm (Hours:Minutes) - Default
• HH - 24 Hours 2 digits 00-23
• H - 24 Hour 1 or 2 digits 0-23
• hh - 12 Hour 2 digits 00-12
• h - 12 Hour 1 or 2 digits 0-12
• mm - minutes 00-59
• a - am/pm indicator

Determines if the Tour Window will display tax values tax inclusive or tax exclusive: Available options are: 'Tax Inclusive and 'Tax Exclusive'.

This INI setting allows the system to enable transaction auditing.

Users can define the number of days to search for recent bookings. The default setting for this is 7 days however users can select an alternative length from 0 - 28 days.

This is a comma delimited list of statuses which can be defined to omit any bookings from showing on the Travelling Booking List.

System-wide setting to default the Tour Window tax radio button to tax INCLUSIVE or tax EXCLUSIVE.

Determines the behaviour of the Tourplan UI on screen, the option selected dictates the UI width allowing it to be 'set' to a specific resolution or for it to 'respond' according to screen size - Available options are.

• Yes - This will allow the UI width to respond to 1366px, 1920px, 2650px, or 3840px depending on the monitor size.

• No - This will set the UI width to 1366px not matter the size of the monitor.

• Always - This will set the UI width to 1920px no matter the size of the monitor.

When set, the user Interface will automatically re-size to suit when not being used on a device that does not have the optimal NX display area. Available options are: Yes, No, Always

These 5 settings are used for labelling the 5 User Defined Text fields which display in the Booking Header screen once the label(s) are set.

The type of data to be entered in the User Text fields - 'Text' or 'Date'.

The default price code that will be used on a service insert if the service chosen does not have the correct agent/booking header price code.

This setting determines whether the Liability Only voucher status must be validated if it is changed. If set to (Y)es, services with a liability voucher status cannot be deleted or substituted.
